Video Mix Split
Splits the video flow into N sub-videos vertically or horizontally.
Example of a video split into 2 videos vertically.
Settings
bypass
Bypasses the module processing when activated (ON).
- OFF (0): Module processes normally
- ON (1): Input passes directly to output without processing
video in
Video input flow(s).
video out
Video output flow(s).
process time
Total time used for the calculation of the module.
position
Position of the split operation.
direction
Split direction, vertically or horizontally.
keep original size
When ON, the outputs keep the same size as the input. Otherwise, outputs are resized.
Common Settings
info
show manual
Opens the web browser to display information or help about the selected object, if it exists.
For more details about information/help creation, see create-help-file.
description
Description of the module for internal help purposes only. The description is not displayed in the interface.
ID's
visible only in god mode, see setup-panel-tab-expert.
unique ID
Current private ID for this control used to identify the object.
preset ID
Current private preset ID for this control used for presets.
recreate ID
If you experience difficulties in Polyphonic mode, try to recreate new id(s) with this button.
repair ID s
Each Patch shared on the local network uses its own ID (identification number). If you experience issues of Patches that don't send information to the good target, this button will rebuild all these id's.
Object Remote Address
absolute
Absolute remote address. see objects-address.
local
Local to the current patch remote address. see objects-address.
user addr
User defined remote address. see objects-address.
