Statistics: Posted by grego mondo — 01 Aug 2026, 10:27
]]>
]]>
le plus simple en terme de programmation, sera d'utiliser un arduino UNO et de simplement interfacer le capteur de distance en I2C pour envoyer les données sur le port série USB.
dans Usine, le module Serial port permettra de récupérer les données. C'est bien pour prototyper, mais personnellement, je ne le recommanderais pas pour une installation perenne ou une tournée !
un teensy2 (ou un clone) programmé par Arduino en mode USBMIDI + un capteur de déplacement VL6180/VL53L0X/VL53L1X (suivant la distance max à mesurer)
Dans ce cas, Usine récupère l'information de distance en midi
il faut faire un microprogramme pour le Teensy pour interfacer le VL qui communique en I2C (cette partie je peux fournir)
limitations : le capteur et le Teensy doivent être à moins de 3m de l'ordinateur
pour des plus grandes distance, il faut passer en OSC, avec un arduino + RJ45 (RPI PICO par exemple) ou wifi (ESP8266)
cette dernière solution est relativement simple, mais la liaison radio est moins fiable...
la solution filaire est très robuste.
l'info de distance sera récupérée par un module OSC receive dans Usine.
++
Olivar
Statistics: Posted by oli_lab — 30 Jul 2026, 19:21
]]>
je cherche à connecter un capteur me donnant une info de distance ou de présence à Usine. Je ne connais plus grand chose aux capteurs et n'en ai jamais branché dans Usine, comment procéder de la manière la plus simple possible ? je vois qu'il y a des capteurs qui peuvent se connecter en usb via un petit convertisseur (usb vers TTL UART ) , est ce que ça fonctionne ? où le récupère t on dans usine? d'autres pistes? merci!! !
Elsa
Statistics: Posted by elsabi — 30 Jul 2026, 17:20
]]>
]]>
Bon été
Statistics: Posted by senso — 27 Jul 2026, 15:05
]]>
Comme d'hab je suis chaud pour une rencontre à Brest mais comme d'hab je bosse beaucoup (trop) donc j'espère pouvoir être dispo
Sinon, comme prévu, on se voit ce week-end à Mellio & à la maison
Statistics: Posted by grego mondo — 22 Jul 2026, 11:10
]]>
Je serai à Millionnec pour le festival "La machine dans le jardin"
Non pas pour tondre, mais pour animer des ateliers de musique électroacoustique improvisée.
C'est Samedi 25 juillet 2026
C'est pour les 6-10 ans, mais j'ai prévu une séance pour les adultes :
10h30 atelier 6-10 ans
11h30 atelier 6-10 ans
14h30 atelier 6-10 ans
15h30 atelier 6-10 ans
17h30 - 18h séance pour les adultes + "ouveture du capot"
++
Olivar
https://lamachinedanslejardin.eu/?page_id=785
Statistics: Posted by oli_lab — 20 Jul 2026, 21:39
]]>
++
Olivar
Statistics: Posted by oli_lab — 16 Jul 2026, 16:49
]]>
you probably don't need all the wiring for duration, use markers and the next marker button
++
Olivar
Statistics: Posted by oli_lab — 16 Jul 2026, 16:46
]]>
It is asked the file Oli_Lab_traceString.usr-macos64uni
Where could I find it ?
Thank you
Statistics: Posted by gwennaelle — 16 Jul 2026, 11:36
]]>
First you have 4 "audio thru" in parralel, I would not do that
Then each sampler also goes to a different out put, is that what you want ?
lot of things and patched anymore, you should remove them (random & reset fader seq)
I can't understand the goal of your your fader "duration" but the out of : [ file duration (in ms) * start pos (in %) + Fader duration (in ms) + 5 (why ?) / file duration ] goes to end position (in %)
I recomand you work on only one instance of your recorder.
clean it, remove everyhting you don't need and understand what you keep
and when it works has intended make several instance of it (polyphonic sub patch or 4 differents patches or the 4 in the same patch being careful with input, outputquicklink ...
have fun
Statistics: Posted by grego mondo — 16 Jul 2026, 10:20
]]>
I made this patch "4 x Loop Rec sampler", and I have 2 questions.
1. the duration.
Sometimes the duration get blocked on a value representing a small part of the file.
Would you know what is the problem in my patch ?
2. the markers.
I'd like to use markers, insert them in real time, and show them.
I tried to enable these settings, but my sampler doesn't have a “Show Markers” option (like in "Template Audio player with markers")
Would you know how to do for my record grain sampler ?
Thank you for your help
Statistics: Posted by gwennaelle — 15 Jul 2026, 18:29
]]>
I made this patch "4 x Loop Rec sampler", and I have 2 questions.
1. the duration.
Sometimes the duration get blocked on a value representing a small part of the file.
Would you know what is the problem in my patch ?
2. the markers.
I'd like to use markers, insert them in real time, and show them.
I tried to enable these settings, but my sampler doesn't have a “Show Markers” option (like in "Template Audio player with markers")
Would you know how to do for my record grain sampler ?
Thank you for your help
Statistics: Posted by gwennaelle — 15 Jul 2026, 18:24
]]>
Je suis entrain de réflechir comment organiser une rencontre-formation des Usineurs Brestois.
J'en connais quelques uns, mais plus on est de fous plus on ri.
pour débutants ou pros.
L'idée serait, entre autre, de proposer quelque chose pour celleux qui n'ont pas accès au stages Afdas.
Au plaisir de vous lire !
Olivar
Statistics: Posted by oli_lab — 13 Jul 2026, 12:57
]]>
I am not a fluent mac user, but I may help :
Did you set up the incoming open port in Usine as the same as the outgoing port in touch OSC ?
then you should check these ports are open in MAC : https://www.hostmyapple.com/blog/mac-fi ... like-a-pro
there is an app for that, or you could use command line directly from Usine with the module "system shell command" https://www.brainmodular.com/manuals/hh ... ll-command
this last bit should be very handy as you can include this command in the patch using touch osc !
cheers
Olivar
Statistics: Posted by oli_lab — 13 Jul 2026, 12:10
]]>
Statistics: Posted by cmodica — 13 Jul 2026, 12:05
]]>
I tried using a shared connection and Touch OSC on iOS. The Touch OSC app successfully receives the messages sent by Usine, but none of the data changes on the Touch OSC screen.
Can anyone help me?
Statistics: Posted by cmodica — 13 Jul 2026, 10:56
]]>
]]>
]]>
Try to reduce the video resolution.
And if you have a video/GPU, take care to use it when you open Usine (not the motherboard)
Statistics: Posted by rlgsbt — 10 Jul 2026, 20:27
]]>
]]>
I' using (or rather trying to use) video in a workspace . My video rack is containing only a video player, a translation patch and scale patch; I can see it's around 1% CPU.
When I use it with some other racks, I got some audio crackling. The global CPU of Usine is around 45%, not more. Any idea of what might cause this?
Thank you in advance
Statistics: Posted by Gilsornette — 10 Jul 2026, 19:33
]]>
Thank you very much for your help.
I have checked the links you shared, and they were very useful. They helped me understand how to approach the project more clearly and gave me practical ideas for implementing it in Usine.
I really appreciate your guidance and the time you took to help me.
Nikos T
Statistics: Posted by NikosT — 08 Jul 2026, 22:24
]]>
here's the patch updated :Thank you but i don't understand why there are not corretly connected ?
GRAIN Cloud FX correctif.zip
Thank you very much. it seems work. But i can't find what did you change in the patch ...
Statistics: Posted by cmodica — 03 Jul 2026, 15:58
]]>
